Specifications
Item
MIG/MAG HRES500 Air-Cooled CO2/Mixed Shielded Welding Torch
Rating
500A CO2/ 400A Mixed Gas, Duty Cycle 60% Wire Diameter: 1.0-1.6mm
Rear Connector
Esab Connector, Esab Euro Connector
Packing
1set/box neutral packing, 5sets/Carton Box
Certification
ISO9001, CCC, CE,
ROHS, TUV
Welding Torch Liner
C366-549-884-B
Steel Liner 0.9-1.0mm, 3m
C366-549-884-B
Steel Liner 0.9-1.0mm, 4.5m
C366-549-884-B
Steel Liner 1.2mm, 3m
C366-549-887-B
Steel Liner 1.2mm, 4.5m
C366-549-890-B
Steel Liner 1.6mm, 3m
C366-549-891-B
Steel Liner 1.6mm, 4.5m
Welding Gas Nozzle/ CO2 torch nozzle
A366-854-884
Nozzle Tapered ￠18mm
Welding Contact tip / Torch tip
B153-502-001
Contact Tip E-CU M8*40*0.9mm
B153-502-002
Contact Tip E-CU M8*40*1.0mm
B153-502-003
Contact Tip E-CU M8*40*1.2mm
B153-502-004
Contact Tip E-CU M8*40*1.4mm
B153-502-005
Contact Tip E-CU M8*40*1.6mm
B153-502-006
Contact Tip E-CU M8*40*2.0mm
Welding Torch Spare parts
D366-396-005
Nozzle Insulator
D366-395-001
Gas Diffuser
D366-396-005
Nozzle Insulator
D366-395-001
Gas Diffuser
D366-397-003
Diffuser Insulation
D366-390-880
Swan Neck
D366-397-003
Diffuser Insulation
D366-390-880
Swan Neck
