Specifications
Item
MIG/MAG HRTW-4 Air-Cooled CO2/Mixed Shielded Welding Torch
Rating
400A CO2/ 350A Mixed Gas , Duty Cycle 60%; Wire Diameter: 0.8-1.6mm
Rear Connector
Tweco, Euro, Miller, Lincoln Connector
Packing
1set/box neutral packing, 5sets/Carton Box
Certification
ISO9001, CCC, CE,
ROHS, TUV
Welding Torch Liner
44-3545-10
Black Steel Liner 0.9-1.2mm,3.4m
44-3545-15
Black Steel Liner 0.9-1.2mm,4.9m
44-116-10
Black Steel Liner 1.6mm,3.4m
44-116-15
Black Steel Liner 1.6mm,4.9m
44-564-10
Black Steel Liner 2.0mm,3.4m
44-564-15
Black Steel Liner 2.0mm,4.9m
Welding Gas Nozzle/ CO2 torch nozzle
HRTW24CT-37-S
Nozzle Tapered ￠9.5mm
HRTW24CT-50-S
Nozzle Conical ￠12.7mm
HRTW24CT-62-S
Nozzle Conical ￠15.9mm
HRTW24CT-75-S
Nozzle Cylindrical ￠19.1mm
Welding Contact tip / Torch tip
14-30
Contact Tip 1/4''-28UNF*38*0.8mm
14-35
Contact Tip 1/4''-28UNF*38*0.9mm
14-40
Contact Tip 1/4''-28UNF*38*1.0mm
14-45
Contact Tip 1/4''-28UNF*38*1.2mm
14-52
Contact Tip 1/4''-28UNF*38*1.3mm
14-116
Contact Tip 1/4''-28UNF*38*1.6mm
Welding Torch Spare parts
94R
Switch
54A
Gas Diffuser
94R
Switch
54A
Gas Diffuser
34CT
Nozzle Insulated
64A-45/60
Swan Neck
34CT
Nozzle Insulated
64A-45/60
Swan Neck
