WP 9 Air Cooled Argon Arc Welding Torch

WP 9 Argon
USER MANUAL

Get Price

Specifications

Item

TIG WP-9 Gas Cooled Tungsten Argon Arc Welding Torch

Rating

125A DC, 80A AC, Tungsten
Diameter: 0.5-1.6mm

Rear Connector

M12*1, 10-25 connector, 3/8''-24 UNF RH, 5/8''-18 UNF RH

Packing

1set/box neutral packing, 5sets/Carton Box

Certification

ISO9001, CCC, CE,
ROHS, TUV

Alumina nozzle/ Ceramic Nozzle

13N08

Std. Ceramic Cup Dia. 6mm

13N09

Std. Ceramic Cup Dia. 8mm

13N10

Std. Ceramic Cup Dia. 10mm

13N11

Std. Ceramic Cup Dia. 11mm

13N12

Std. Ceramic Cup Dia. 13mm

13N13

Std. Ceramic Cup Dia. 16mm

CONSUMABLES PARTS

598882

Heat Shield Cup Gasket

WP-9

Torch body

98W77

Back Cap " O " Ring

41V24

Back Cap Long

41V35

Back Cap Medium

41V33

Back Cap Short

950

Micro Switch Bulbous Button

950F

Micro Switch Flat Button

950-40

Bulbous Micro switch C/W 4mt 2 Core Cable

950-80

Bulbous Micro switch C/W 8mt 2 Core Cable

Collet

13N20

Collet Dia.0.5mm

13N21

Collet Dia.1.0mm

13N22

Collet Dia.1.6mm

Collet Body

13N25

Collet Body Dia. 0.5mm

13N26

Collet Body Dia. 1.0mm

13N27

Collet Body Dia. 1.6mm

Gas Lens Collet Body

45V41

Gas Lens Body Dia. 0.5mm

45V42

Gas Lens Body Dia. 1.0mm

45V43

Gas Lens Body Dia. 1.6mm

CONSUMABLES PARTS

RDZ0591

Switch Boot

607664

Switch Retaining Boot

105Z55

Handle

0315071

Insulation Boot

54N63-20

Heat Shield Cup Gasket

WP-9V

Torch Body With Valve

VS-2

Valve Stem

WP-9FX

Flexible Torch Body

WP-9P

Straight Torch Body

Note: All mentioned names, Trademarks and Part No. are the property of their respective manufacturers, all consumables are not original, are manufactured and sold by HUARUI CO., reference to the original manufacturer is for convenience only
